Specifications
Main Frame | Q235B manganese plates, automatic submerged arc welded |
Floor | Steel Sheet 3mm thickness or diamond plate(Also can choose other thickness, such as 2mm, 2.3mm, 4mm, 5mm, 6mm) |
Axle | 13T FUWA (BPW optional) |
Suspension | Independent stamping steel rigid suspension ( air suspension) |
King Pin | 2" or 3.5" Chinese traction pin ( JOST optional) |
Landing Gear | Chinese brand loading 28000kg (JOST optional |
Wheel Rim | 12 units of 8.0-20 9.0-20 |
Tyre | 12 units of 11.00R20/12R22.5 16PR steel tyre |
Spare Wheel Carrier | One set of spare wheel carrier including a riser. |
Braking System | KEMI or other Brand of China; ABS (optional ) |
Brake Air Chamber | Four double and two single chamber |
Electrical System | 1. Voltage: 24v 2. Receptacle: 7 ways(7 wire harness) |
Painting | Sand blasting processing clean rust 1 coat of anti corrosive primer 2 coats of finish urethane paint Color as customer need |
Accessory | One tooling box with a set of standard trailer tool |
Other Descriptions | The cargo platform is lower than others, is applicable for unsound road condition, ensuring the stability of the transportation. |
Remark | we can designed model according to client's requirement |


It Is applicable for the transplantation of the mechanical equipment, large objects, highway construction equipment, large tanks, power plant equipment or
machine, and all sorts of steel products.
